ThermoScan 3208 - Measuring and Recording Temperature and Humidity

The ThermoScan 3208 is a system, microcontroller based, with a LCD display (2 lines / 20 characters). In this display you can see the temperatures and humidity. This display shows 4 channels simultaneously.

Download Brochure

The ThermoScan 3208 system is used to view and record in real-time temperature and humidity of product manufacturing plants refrigerators, appliances, electronic equipment, fixtures, machine tools, etc.

The ThermoScan 3208 system, microcontroller based, with a LCD display (2 lines / 20 characters). In this display you can see the temperatures and humidity. This display shows 4 channels simultaneously.

The ThermoScan 3208 system has a USB output to connect it to the PC on which the software is running and record each of the parameters.

The ThermoScan 3208 Software lets you view and record the data from each channels. The software allows you to print the recorded curves as well as, to export to CVS file (comma separator) or PDF.

The ThermoScan 3208 system sends the measurement data via FTP to www.thermoscan.com.ar website (it have extra cost), to see the behavior of the devices under test when one is not in front of the PC graphic data (eg weekends).



Hardware Specifications
Measurement range: -30ºC a +70ºC.
Resolution: 0.1 ºC
Accuracy: +/- 1ºC.
Measurement channels:
  • Temperature: 32 channels.
  • Humidity: 8 channels.
Time between measurement: 30 Seconds.
Output / Input: USB (Output & Input of data).
Calibration Report:

in 3 points to:

  • -20 ºC (approx.)
  • 0 ºC (approx.)
  • 30 ºC (approx.)
Power Supply: 220Vca, 50 Hz, 6 A, single phase (115 Vca optional).
Software Specifications
Specifications:
  • Software very easy to use.
  • Saves the values of each test in real time to protect against possible loss data.
  • Makes Test List.
  • Export to CSV files (ASCII format).
  • Screen to Calibration.
  • Print Graph report.
  • Restricted access with user and password.
  • User Manual.
Requeriments:
  • O.S.: Windows Xp / 7.
  • 1 USB Port.
  • Resolution: 1600px x 900px
